Architectural Services

Architectural Drafting and Design Services:

Architectural 2d drafting:
We offer all types of Architectural 2d Drafting services to help you in making paper less working environment and digitize your drawings and ideas.
We do the following services:
1. Interior and Exterior models of buildings.
2. Furniture and Fixtures of offices, residences, clubs & hotels, hospitals etc.
3. Product Modeling.
4. Photo Montage & Landscaping.
Animation & Walkthroughs:
We create quality animation & walkthroughs with latest animation software available today to meet industry demands. We can convert 3D models in to walkthrough, giving you a feel of reality to your concept/product/buildings.

Structural Services

We provide complete details for each steel member, its fastening details, hardware list and the match-mark. Using the customer prescribed CAD Software we can customize the drawings as per specific need of marking schemes (Sheet size, layering, text style, etc.). AISC codes and other standards are followed as per design requirement.
We provide drawings for a variety of structures including:
1. Space frames and utility towers
2. Conveyor galleries and supports
3. Equipment supports
4. Tanks, bunkers, silos and hoppers
5. Pressure vessels
Structural steel detailing:
We undertake detailing of industrial / commercial buildings, towers, storage bunkers and silos, junction houses, ducts, pipe racks, galleries and walkways, access stairways, equipment supports and other plant structures.
